7PGA

Chimeric carminomycin-4-O-methyltransferase (DnrK) with regions from 10-hydroxylase RdmB and 10-decarboxylase TamK


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.77 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.201
  • R-Value Observed: 0.203

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Evolution-inspired engineering of anthracycline methyltransferases.

Dinis, P.Tirkkonen, H.Wandi, B.N.Siitonen, V.Niemi, J.Grocholski, T.Metsa-Ketela, M.

(2023) PNAS Nexus 2: pgad009-pgad009

  • DOI: https://doi.org/10.1093/pnasnexus/pgad009
  • Primary Citation of Related Structures:
    7OWB, 7OY1, 7PG7, 7PGA, 7PGJ, 7PHD, 7PHE, 7PHF

  • PubMed Abstract:

    Streptomyces soil bacteria produce hundreds of anthracycline anticancer agents with a relatively conserved set of genes. This diversity depends on the rapid evolution of biosynthetic enzymes to acquire novel functionalities. Previous work has identified S -adenosyl-l-methionine-dependent methyltransferase-like proteins that catalyze 4-O-methylation, 10-decarboxylation, or 10-hydroxylation, with additional differences in substrate specificities. Here we focused on four protein regions to generate chimeric enzymes using sequences from four distinct subfamilies to elucidate their influence in catalysis. Combined with structural studies we managed to depict factors that influence gain-of-hydroxylation, loss-of-methylation, and substrate selection. The engineering expanded the catalytic repertoire to include novel 9,10-elimination activity, and 4-O-methylation and 10-decarboxylation of unnatural substrates. The work provides an instructive account on how the rise of diversity of microbial natural products may occur through subtle changes in biosynthetic enzymes.


  • Organizational Affiliation

    Department of Life Technologies, University of Turku, BioCity, Tykistökatu 6, FIN-20014 Turku, Finland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carminomycin 4-O-methyltransferase DnrK,Methyltransferase domain-containing protein,Aclacinomycin 10-hydroxylase RdmB
A, B, C, D
368Streptomyces peucetiusStreptomyces tsukubensis NRRL18488Streptomyces purpurascensMutation(s): 0
Gene Names: dnrKSTSU_011780STSU_11775rdmB
EC: 2.1.1.292 (PDB Primary Data), 4.1.1 (PDB Primary Data)
UniProt
Find proteins for Q54527 (Streptomyces purpurascens)
Explore Q54527
Go to UniProtKB:  Q54527
Find proteins for Q06528 (Streptomyces peucetius)
Explore Q06528
Go to UniProtKB:  Q06528
Find proteins for I2N5E8 (Streptomyces tsukubensis (strain DSM 42081 / NBRC 108919 / NRRL 18488 / 9993))
Explore I2N5E8
Go to UniProtKB:  I2N5E8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsI2N5E8Q06528Q54527
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
VAK (Subject of Investigation/LOI)
Query on VAK

Download Ideal Coordinates CCD File
F [auth A],
H [auth B],
J [auth C],
L [auth D]
methyl (1R,2R,4S)-2-ethyl-2,4,5,7-tetrahydroxy-6,11-dioxo-1,2,3,4,6,11-hexahydrotetracene-1-carboxylate
C22 H20 O8
RACGRCLGVYXIAO-YOKWENHESA-N
SAH (Subject of Investigation/LOI)
Query on SAH

Download Ideal Coordinates CCD File
E [auth A],
G [auth B],
I [auth C],
K [auth D]
S-ADENOSYL-L-HOMOCYSTEINE
C14 H20 N6 O5 S
ZJUKTBDSGOFHSH-WFMPWKQPSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.77 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.201
  • R-Value Observed: 0.203
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.47α = 90
b = 102.64β = 98.23
c = 121.85γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-08-24
    Type: Initial release
  • Version 1.1: 2023-03-22
    Changes: Database references
  • Version 1.2: 2024-02-07
    Changes: Data collection, Refinement description
