2YAN | pdb_00002yan

Crystal structure of the second glutaredoxin domain of human TXNL2

PDB DOI: https://doi.org/10.2210/pdb2YAN/pdb

Classification: OXIDOREDUCTASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2011-02-23 Released: 2011-11-30
Deposition Author(s): Vollmar, M., Johansson, C., Cocking, R., Muniz, J.R.C., Krojer, T., Allerston, C., von Delft, F., Bountra, C., Arrowsmith, C.H., Weigelt, J., Edwards, A., Oppermann, U.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.212 (Depositor), 0.210 (DCC)
R-Value Work:
0.185 (Depositor), 0.180 (DCC)
R-Value Observed:
0.186 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history.

Literature

Crystal Structure of the Second Glutaredoxin Domain of Human Txnl2

Vollmar, M., Johansson, C., Cocking, R., Muniz, J.R.C., Krojer, T., Allerston, C., von Delft, F., Bountra, C., Arrowsmith, C.H., Weigelt, J., Edwards, A., Oppermann, U.

To be published.

Macromolecule Content

Total Structure Weight: 25.05 kDa
Atom Count: 2,018
Modelled Residue Count: 210
Deposited Residue Count: 210
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GLUTAREDOXIN-3	A, B	105	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for O76003 (Homo sapiens) Explore O76003 Go to UniProtKB: O76003
PHAROS: O76003 GTEx: ENSG00000108010
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O76003
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GSH Query on GSH Download Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain N [auth B] MOL2 format, chain J [auth A] MOL2 format, chain N [auth B] mmCIF format, chain J [auth A] mmCIF format, chain N [auth B]	J [auth A], N [auth B]	GLUTATHIONE C₁₀ H₁₇ N₃ O₆ S RWSXRVCMGQZWBV-WDSKDSINSA-N		Interactions Focus chain J [auth A] Focus chain N [auth B] Interactions & Density Focus chain J [auth A] Focus chain N [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain M [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B]	C [auth A] D [auth A] E [auth A] F [auth A] K [auth B] C [auth A], D [auth A], E [auth A], F [auth A], K [auth B], L [auth B], M [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]
FE Query on FE Download Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.212 (Depositor), 0.210 (DCC)
R-Value Work: 0.185 (Depositor), 0.180 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 118.317	α = 90
b = 118.317	β = 90
c = 58.84	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2011-11-30

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2011-11-30
Type: Initial release
Version 1.1: 2012-01-18
Changes: Other
Version 1.2: 2012-12-05
Changes: Database references
Version 1.3: 2018-01-24
Changes: Database references
Version 1.4: 2023-12-20
Changes: Data collection, Database references, Derived calculations, Other, Refinement description
