2HQ7 | pdb_00002hq7

Crystal structure of Protein related to general stress protein 26(GS26) of B.subtilis (pyridoxinephosphate oxidase family) (NP_350077.1) from CLOSTRIDIUM ACETOBUTYLICUM at 2.00 A resolution

PDB DOI: https://doi.org/10.2210/pdb2HQ7/pdb

Classification: OXIDOREDUCTASE
Organism(s): Clostridium acetobutylicum
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2006-07-18 Released: 2006-08-15
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.242 (Depositor), 0.240 (DCC)
R-Value Work:
0.191 (Depositor), 0.200 (DCC)
R-Value Observed:
0.193 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of Protein related to general stress protein 26(GS26) of B.subtilis (pyridoxinephosphate oxidase family) (NP_350077.1) from CLOSTRIDIUM ACETOBUTYLICUM at 2.00 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 35.07 kDa
Atom Count: 2,444
Modelled Residue Count: 283
Deposited Residue Count: 292
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein, related to general stress protein 26(GS26) of B.subtilis	A, B	146	Clostridium acetobutylicum	Mutation(s): 7 Gene Names: NP_350077.1
UniProt
Find proteins for Q97DI6 (Clostridium acetobutylicum (strain ATCC 824 / DSM 792 / JCM 1419 / IAM 19013 / LMG 5710 / NBRC 13948 / NRRL B-527 / VKM B-1787 / 2291 / W)) Explore Q97DI6 Go to UniProtKB: Q97DI6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q97DI6
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain H [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain H [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain H [auth B]	D [auth A], E [auth A], F [auth A], H [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain G [auth B] MOL2 format, chain C [auth A] MOL2 format, chain G [auth B] mmCIF format, chain C [auth A] mmCIF format, chain G [auth B]	C [auth A], G [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain G [auth B] Interactions & Density Focus chain C [auth A] Focus chain G [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.242 (Depositor), 0.240 (DCC)
R-Value Work: 0.191 (Depositor), 0.200 (DCC)
R-Value Observed: 0.193 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32HQ7

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 85.85	α = 90
b = 36.79	β = 113.75
c = 97.97	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
SHELX	phasing
REFMAC	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
autoSHARP	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2006-08-15

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2006-08-15
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.3: 2017-10-18
Changes: Refinement description
Version 1.4: 2023-01-25
Changes: Database references, Derived calculations
Version 1.5: 2024-10-30
Changes: Data collection, Structure summary
