2H1I | pdb_00002h1i

Crystal Structure of the Bacillus cereus Carboxylesterase

PDB DOI: https://doi.org/10.2210/pdb2H1I/pdb

Classification: HYDROLASE
Organism(s): Bacillus cereus ATCC 14579
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2006-05-16 Released: 2006-05-30
Deposition Author(s): Minasov, G., Shuvalova, L., Collart, F.R., Joachimiak, A., Anderson, W.F., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free:
0.230 (Depositor), 0.226 (DCC)
R-Value Work:
0.167 (Depositor), 0.165 (DCC)
R-Value Observed:
0.170 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal Structure of the Bacillus cereus Carboxylesterase

Minasov, G., Shuvalova, L., Collart, F.R., Anderson, W.F.

To be published.

Macromolecule Content

Total Structure Weight: 77.57 kDa
Atom Count: 5,074
Modelled Residue Count: 619
Deposited Residue Count: 678
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carboxylesterase	A, B, C	226	Bacillus cereus ATCC 14579	Mutation(s): 0 Gene Names: AAP10572 EC: 3.1.1.1
UniProt
Find proteins for Q81AD5 (Bacillus cereus (strain ATCC 14579 / DSM 31 / CCUG 7414 / JCM 2152 / NBRC 15305 / NCIMB 9373 / NCTC 2599 / NRRL B-3711)) Explore Q81AD5 Go to UniProtKB: Q81AD5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q81AD5
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain G [auth B] SDF format, chain L [auth C] MOL2 format, chain D [auth A] MOL2 format, chain G [auth B] MOL2 format, chain L [auth C] mmCIF format, chain D [auth A] mmCIF format, chain G [auth B] mmCIF format, chain L [auth C]	D [auth A], G [auth B], L [auth C]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain G [auth B] Focus chain L [auth C] Interactions & Density Focus chain D [auth A] Focus chain G [auth B] Focus chain L [auth C]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] SDF format, chain I [auth B] SDF format, chain M [auth C] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] MOL2 format, chain M [auth C] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B] mmCIF format, chain I [auth B] mmCIF format, chain M [auth C]	E [auth A], H [auth B], I [auth B], M [auth C]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain M [auth C] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain M [auth C]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] MOL2 format, chain F [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] mmCIF format, chain F [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C]	F [auth A], J [auth B], K [auth B], N [auth C], O [auth C]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain O [auth C] Interactions & Density Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain O [auth C]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free: 0.230 (Depositor), 0.226 (DCC)
R-Value Work: 0.167 (Depositor), 0.165 (DCC)
R-Value Observed: 0.170 (Depositor)

Space Group: P 6₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.607	α = 90
b = 99.607	β = 90
c = 160.234	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
SHARP	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2006-05-30

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2006-05-30
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Source and taxonomy, Version format compliance
Version 1.3: 2024-10-30
Changes: Data collection, Database references, Derived calculations, Structure summary
