1YTL | pdb_00001ytl

Crystal Structure of Acetyl-CoA decarboxylase/synthase complex epsilon subunit 2

PDB DOI: https://doi.org/10.2210/pdb1YTL/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Archaeoglobus fulgidus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2005-02-10 Released: 2005-03-22
Deposition Author(s): Chang, C., Evdokimova, E., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.214 (Depositor), 0.210 (DCC)
R-Value Work:
0.171 (Depositor), 0.170 (DCC)
R-Value Observed:
0.173 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal Structure of Acetyl-CoA decarboxylase/synthase complex epsilon subunit 2 from Archaeoglobus fulgidus

Chang, C., Evdokimova, E., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 78.38 kDa
Atom Count: 5,606
Modelled Residue Count: 631
Deposited Residue Count: 696
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acetyl-CoA decarboxylase/synthase complex epsilon subunit 2	A, B, C, D	174	Archaeoglobus fulgidus	Mutation(s): 0 Gene Names: cdhB2
UniProt
Find proteins for O30273 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16)) Explore O30273 Go to UniProtKB: O30273
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O30273
Sequence Annotations Expand
Reference Sequence LOADING

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.214 (Depositor), 0.210 (DCC)
R-Value Work: 0.171 (Depositor), 0.170 (DCC)
R-Value Observed: 0.173 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.664	α = 93.92
b = 61.944	β = 103.64
c = 71.198	γ = 94.14

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling
MLPHARE	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2005-03-22

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2005-03-22
Type: Initial release
Version 1.1: 2008-04-30
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.3: 2024-02-14
Changes: Data collection, Database references
