8YX5

Crystal Structure of SARS CoV-2 Papain-like Protease PLpro-C111S in Complex with GZNL-P35


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.74 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.170
  • R-Value Observed: 0.172

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Discovery of orally bioavailable SARS-CoV-2 papain-like protease inhibitor as a potential treatment for COVID-19.

Lu, Y.Yang, Q.Ran, T.Zhang, G.Li, W.Zhou, P.Tang, J.Dai, M.Zhong, J.Chen, H.He, P.Zhou, A.Xue, B.Chen, J.Zhang, J.Yang, S.Wu, K.Wu, X.Tang, M.Zhang, W.K.Guo, D.Chen, X.Chen, H.Shang, J.

(2024) Nat Commun 15: 10169-10169

  • DOI: https://doi.org/10.1038/s41467-024-54462-0
  • Primary Citation of Related Structures:
    8YX2, 8YX3, 8YX4, 8YX5

  • PubMed Abstract:

    The RNA-dependent RNA polymerase (RdRp), 3C-like protease (3CL pro ), and papain-like protease (PL pro ) are pivotal components in the viral life cycle of SARS-CoV-2, presenting as promising therapeutic targets. Currently, all FDA-approved antiviral drugs against SARS-CoV-2 are RdRp or 3CL pro inhibitors. However, the mutations causing drug resistance have been observed in RdRp and 3CL pro from SARS-CoV-2, which makes it necessary to develop antivirals with novel mechanisms. Through the application of a structure-based drug design (SBDD) approach, we discover a series of novel potent non-covalent PL pro inhibitors with remarkable in vitro potency and in vivo PK properties. The co-crystal structures of PL pro with lead compounds reveal that the residues D164 and Q269 around the S2 site are critical for improving the inhibitor's potency. The lead compound GZNL-P36 not only inhibits SARS-CoV-2 and its variants at the cellular level with EC 50 ranging from 58.2 nM to 306.2 nM, but also inhibits HCoV-NL63 and HCoV-229E with EC 50 of 81.6 nM and 2.66 μM, respectively. Oral administration of the GZNL-P36 results in significantly improved survival and notable reductions in lung viral loads and lesions in SARS-CoV-2 infection mouse model, consistent with RNA-seq data analysis. Our results indicate that PL pro inhibitors represent a promising SARS-CoV-2 therapy.


  • Organizational Affiliation

    Guangzhou National Laboratory, Guangzhou, 510005, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Papain-like protease nsp3
A, B
316Severe acute respiratory syndrome coronavirus 2Mutation(s): 1
Gene Names: rep1a-1b
EC: 3.4.19.12 (PDB Primary Data), 3.4.22 (PDB Primary Data)
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1LZ8 (Subject of Investigation/LOI)
Query on A1LZ8

Download Ideal Coordinates CCD File
C [auth A],
H [auth B]
5-[(1~{R},5~{S})-3,6-diazabicyclo[3.1.1]heptan-3-yl]-2-methyl-~{N}-[1-(1-methyl-2-oxidanylidene-benzo[cd]indol-6-yl)cyclopropyl]benzamide
C28 H28 N4 O2
NSNJCLUPOYTRHK-HDICACEKSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
F [auth A],
G [auth A],
K [auth B],
L [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
I [auth B],
J [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.74 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.170
  • R-Value Observed: 0.172
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.87α = 90
b = 144.97β = 99.24
c = 60.1γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata scaling
autoXDSdata reduction
PHASESphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)ChinaGZNL2023401008
Ministry of Science and Technology (MoST, China)ChinaSRPG22-002
Ministry of Science and Technology (MoST, China)ChinaSRPG22-003
National Natural Science Foundation of China (NSFC)China82170473

Revision History  (Full details and data files)

  • Version 1.0: 2024-12-04
    Type: Initial release
