3BO9 | pdb_00003bo9

Crystal structure of putative nitroalkan dioxygenase (TM0800) from Thermotoga maritima at 2.71 A resolution

PDB DOI: https://doi.org/10.2210/pdb3BO9/pdb

Classification: OXIDOREDUCTASE
Organism(s): Thermotoga maritima MSB8
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2007-12-17 Released: 2007-12-25
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.71 Å
R-Value Free:
0.211 (Depositor), 0.210 (DCC)
R-Value Work:
0.189 (Depositor), 0.190 (DCC)
R-Value Observed:
0.190 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of putative nitroalkan dioxygenase (TM0800) from Thermotoga maritima at 2.71 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 76.13 kDa
Atom Count: 4,850
Modelled Residue Count: 628
Deposited Residue Count: 652
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative nitroalkan dioxygenase	A, B	326	Thermotoga maritima MSB8	Mutation(s): 0 Gene Names: TM0800 EC: 1.3.1.9
UniProt
Find proteins for Q9WZQ7 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9WZQ7 Go to UniProtKB: Q9WZQ7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9WZQ7
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
2PE Query on 2PE Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B]	I [auth A] J [auth A] K [auth A] L [auth A] P [auth B] I [auth A], J [auth A], K [auth A], L [auth A], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B]	NONAETHYLENE GLYCOL C₁₈ H₃₈ O₁₀ YZUUTMGDONTGTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain N [auth B] SDF format, chain O [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B]	D [auth A] E [auth A] F [auth A] G [auth A] N [auth B] D [auth A], E [auth A], F [auth A], G [auth A], N [auth B], O [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain N [auth B] Focus chain O [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain N [auth B] Focus chain O [auth B]
PO4 Query on PO4 Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain M [auth B] MOL2 format, chain C [auth A] MOL2 format, chain M [auth B] mmCIF format, chain C [auth A] mmCIF format, chain M [auth B]	C [auth A], M [auth B]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain C [auth A] Focus chain M [auth B] Interactions & Density Focus chain C [auth A] Focus chain M [auth B]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.71 Å
R-Value Free: 0.211 (Depositor), 0.210 (DCC)
R-Value Work: 0.189 (Depositor), 0.190 (DCC)
R-Value Observed: 0.190 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33BO9

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 128.058	α = 90
b = 128.058	β = 90
c = 161.678	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
MOSFLM	data reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2007-12-25

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2007-12-25
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2017-10-25
Changes: Refinement description
Version 1.3: 2019-07-24
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-01-25
Changes: Database references, Derived calculations
Version 1.5: 2024-10-30
Changes: Data collection, Refinement description, Structure summary
